Ubiquiti UniFi UXG-PRO Next-generation Gateway Pro 10G HyperFibre Router, Dual-Wan with failover, 10G SFP+ x2, Enterprise-class DPI, IPS/IDS

Features

Dual-WAN security gateway designed to protect medium to large-sized networks with enterprise-class firewall configuration and threat management features.

The UniFi Next-Generation Gateway Pro (UXG Pro) is a powerful security gateway that delivers a versatile networking interface and enterprise-class threat management functionality to medium to large-sized networks. The UXG Pro is equipped with (2) WAN ports (GbE RJ45 and 10G SFP+) that provide failover support, as well as (2) LAN ports (GbE RJ45 and 10G SFP+) to provide the high-speed connectivity needed to support the most bandwidth-intensive applications. It also excels as a complete network security solution, offering a full suite of threat mitigation features, including deep packet inspection (DPI), intrusion detection and prevention systems (IDS/IPS), and layered firewall configuration. The UXG Pro can be paired with a Cloud Key Plus to create a highly powerful and secure deployment that can be fully managed with the UniFi Network application (web/mobile).

Features

 - 1.7 GHz quad-core processor
 - (2) WAN ports (GbE RJ45 and 10G SFP+) with failover support
 - (2) LAN ports (GbE RJ45 and 10G SFP+)
 - Enterprise-class DPI, IPS/IDS, and layered firewall configuration
 - Power redundancy when connected to the UniFi SmartPower RPS (sold separately)
 - SmartPower outlet (125VAC/2A) for an external modem
 - 1U-sized, rack-mountable device

Managed with the UniFi Network application: Version 5.14.11 and later

Works with the UniFi Network Application

 - Centrally manage multiple networks from an intuitive interface
 - Enjoy real-time device insights and deep configuration options
 - Upgrade device firmware remotely
 - Manage network users and guests with ease
 - Personalize the design, architecture, and privacy of guest hotspots
 - Set up devices quickly and manage them on the go with a powerful mobile app

Specifications

Mechanical

Dimensions

442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24")

Weight

3.42 kg (7.54 lb)

Enclosure materials

Front panel: aluminum CNC
Top cover/base: SGCC steel

Hardware

Processor

Quad-core ARM® Cortex®-A57 at 1.7 GHz

Memory information

2 GB DDR4

Management interface

Ethernet

Networking interface

LAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ port

WAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ port

LCM display

(1) 1.3" touchscreen
Bootup animation: bootup in progress
Firmware upgrade icon: firmware upgrading

Button

Factory reset

Power method

US

(1) Universal AC input, 125VAC, 2.7A max., 60 Hz
(1) RPS DC input, 11.5VDC, 2.87A

Worldwide

(1) Universal AC input, 200-240VAC, 1.7A max., 50/60 Hz
(1) RPS DC input, 11.5VDC, 2.87A

Power supply

AC/DC, internal, 50W

Max. power consumption

30W

ESD/EMP protection

Air: ± 15 kV, contact: ± 8 kV

Operating temperature

-10 to 40° C (14 to 104° F)

Operating humidity

5 - 95% noncondensing

Certifications

CE, FCC, IC

LEDs

AC outlet/ RPS

Blue

Ethernet

Green/amber

SFP+

White/green
